MX-M260/M310/M260N/M310N CONSUMABLE PARTS 3 - 3
C. STCL/ SRH/ SRS/ SRSSC/ SBI/ Agent (MX-M260/M310/M260N/M310N)
∗ The other maintenance parts than the above are supplied as service parts.
3. Developer/Drum life end definition
When the developer/drum counter reaches the specified level.
When the developer/drum rpm reaches the specified level.
When either of the above reached the specified level, it is judged as life end.
In an actual case, when correction or warm-up operation is performed as well as output operation, the developer and the drum rotates.
Therefore, the developer/drum consuming level cannot be determined only by the copy/print quantity. When, therefore, the rpm reaches the specified
level, it is judged as life end.
To check the drum and developer life, use SIM22-1.
No. Item Content Life
Model
name
Remarks
1 Upper heat roller kit Upper heat roller
Fuser gear
Upper heat roller bearing
Upper cleaning pad
Fusing separation pawl (upper)
Thermistor cleaning pad
×1
×1
×2
×1
×4
×2
150K AR-310UH
2 Lower heat roller kit Lower heat roller
Fusing separation pawl (lower)
Fuser bearing (lower)
×1
×4
×2
300K MX-311LH
3 150K PM kit Drum separation pawl unit
Transfer roller unit
DV blade
DV side sheet F
DV side sheet R
Toner filter unit
×2
×1
×1
×1
×1
×1
150K MX-311KA
4 MC unit MC unit ×10 26cpm: 75K (×10)
31cpm: 100K (×10)
MX-311MC
5 Cleaner blade Cleaner blade ×10 26cpm: 75K (×10)
31cpm: 100K (×10)
MX-311CB
6 Drum frame unit Drum frame unit ×1 26cpm: 225K
31cpm: 300K
MX-311DU
∗ The life of the toner reception seat attached to
the drum frame is 300K, and it can be used up
to 3 times. (Supplied as a drum frame unit.)
7 Staple cartridge Staple cartridge ×3 5000 staples ×3 MX-SCX1
Developer/drum counter
Number of rotations
(Rotations)
Developer/drum 26cpm model 31cpm model 550K
75K 100K
