Sharp MX-M260 Service Manual

MX-M260/M310/M260N/M310N MAINTENANCE 8 - 1
[8] MAINTENANCE
1. Maintenance list
(For 26cpm)
✕: Check (Check, clean, replace or adjust according to necessity.)
❍: Cleaning ▲ : Replace ✩: Lubricate
Unit Parts 75k 150k 225k 300k 375k 450k 525k 600k Note
Process Drum ▲▲▲▲▲▲▲▲
Cleaner blade ▲▲▲▲▲▲▲▲
Seal F/R ✕✕✕✕✕✕✕✕
Drum frame unit
(Toner reception sheet)
✕✕▲✕✕▲✕✕
Usable for three PM cycles
MC unit ▲▲▲▲▲▲▲▲
Separation pawl unit ✕▲✕▲✕▲✕▲
Star ring ▲▲▲▲▲▲▲▲
DV Developer ▲▲▲▲▲▲▲▲
Toner filter unit ▲▲▲▲▲▲▲▲
DV blade ✕▲✕▲✕▲✕▲
DV side sheet F ✕▲✕▲✕▲✕▲
DV side sheet R ✕▲✕▲✕▲✕▲
Toner sensor ✕✕✕✕✕✕✕✕
Fusing Upper heat roller ❍▲ ❍▲ ❍▲ ❍▲
Lower heat roller ❍❍❍▲❍❍❍▲
Upper separation pawl ❍▲ ❍▲ ❍▲ ❍▲
Upper cleaning pad ✕▲✕▲✕▲✕▲
Lower separation pawl ❍❍❍▲❍❍❍▲
Thermistor ❍❍❍❍❍❍❍❍
Fuser gear ✩▲✩▲✩▲✩▲
Upper heat roller bearing ✕▲✕▲✕▲✕▲
Lower fuser bearing ✕✕✕▲✕✕✕▲
Thermistor cleaning pad ✕▲✕▲✕▲✕▲
Paper guide ❍❍❍❍❍❍❍❍
Paper feed Pickup roller ✕✕✕✕✕✕✕✕Changing criteria for parts: 100k
Paper feeding sheet ✕✕✕✕✕✕✕✕
Pickup roller and feed roller
(RSPF)
✕✕✕✕✕✕✕✕
Transport Transport roller unit ❍▲ ❍▲ ❍▲ ❍▲
Gear ✕ – ✕ – ✕ – ✕ –
Others Paper feed rollers ❍❍❍❍❍❍❍❍
Gears ✩✩✩✩✩✩✩✩
Ozone filter ▲▲▲▲▲▲▲▲

Sharp MX-M260 Specifications

General

Print Technology	Laser
Print Speed	26 ppm
Max Print Resolution	600 x 600 dpi
Copy Speed	26 cpm
Max Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Warm-up Time	25 seconds
Fax Resolution	200 x 200 dpi
Paper Capacity	1, 100 sheets
Max Paper Size	A3
Duplex Printing	Yes
Functions	Print, Copy, Scan
Zoom Range	25% to 400%
Supported Paper Sizes	A4, A5, B5
Network Connectivity	Optional (Ethernet)
USB Connectivity	USB 2.0
Weight	28.5 kg
