MX-M260/M310/M260N/M310N SIMULATION 6 - 18
Detection size when 8.5” x 13” document/paper is used.
A4/LT (8.5” x 11”) detection enable/disable setup
In the inch series, Letter is detected as A4; in the AB series, A4 is
detected as Letter.
Detection size when A4/LT (8.5” x 11”) document/paper is used.
Operation/procedure
Select the mode corresponding to the auditor specification mode with
the 10-key.
When “1: VENDOR (Coin vendor mode)” is set, the following three
items of key operation setting are changed.
1) Set the LCD backlight change inhibit to “1: OFF (Enable).”
2) When SIM 26-6 destination setting is set to “0: Japan,” duplex copy
inhibit setting must be set to “0: ON (Inhibit).”
3) Set the sort automatic selection to “0: OFF (Disable).”
Operation/procedure
Used to set the count up number (1 or 2) when an A3/WLT paper
passes through.
For the drum counter and the developer counter, double count is
employed unconditionally.
(Target counter selection)
Used to set the count up number of the selected counter.
Operation/procedure
Select the destination with the 10-key.
By changing the destination, some other setting items may be changed.
Employed
unit
Destina
tion
Document
size
Set value
0
(Invalid)
1
(Valid)
Docu
ment
Document
table/
RSPF
AB
series
FC
(8.5” x 13”)
B4
FC
(8.5” x 13”)
LG
(8.5” x 14”)
B4
FC
(8.5” x 13”)
B4 B4
FC
(8.5” x 13”)
Inch
series
FC
(8.5” x 13”)
LG
(8.5” x 14”)
FC
(8.5” x 13”)
LG
(8.5” x 14”)
LG
(8.5” x 14”)
FC
(8.5” x 13”)
B4
WLT
(11” x 17”)
WLT
(11” x 17”)
Paper
Machine
paper feed
tray
All
destina
tions
– Set with key operations.
Manual
paper feed
tray
AB
series
FC
(8.5” x 13”)
LG
(8.5” x 14”)
FC
(8.5” x 13”)
LG
(8.5” x 14”)
LG
(8.5” x 14”)
FC
(8.5” x 13”)
B4 B4 B4
Inch
series
FC
(8.5” x 13”)
LG
(8.5” x 14”)
FC
(8.5” x 13”)
LG
(8.5” x 14”)
LG
(8.5” x 14”)
FC
(8.5” x 13”)
B4 B4 B4
Set value Setup Remarks
0 Detection invalid Default
1 Detection valid
Employed
unit
Destina
tion
Document
size
Set value
0
(Invalid)
1
(Valid)
Docu
ment
Document
table/
RSPF
AB
series
A4 A4
LT
(8.5” x 11”)
LT
(8.5” x 11”)
A4
LT
(8.5” x 11”)
Inch
series
A4
LT
(8.5” x 11”)
A4
LT
(8.5” x 11”)
LT
(8.5” x 11”)
A4
Paper
Machine
paper feed
tray
All
destina
tions
–
Set with key
operations.
Manual
paper feed
tray
All
destina
tions
–
Regardless of the
simulation setup.
26-3
Purpose Setting
Function
(Purpose)
Used to set the specifications of the auditor.
Setting must be made depending on the use condition
of the auditor.
Section Auditor
Item Specifications
Item Content
Setting
range
Default
0
P10
Built-in auditor mode
0-2 01
VENDOR
Coin vendor mode
2
OTHER
Others
26-5
Purpose Setting
Function
(Purpose)
Used to set the count mode of the total counter and the
maintenance counter.
Item Specifications Counter
Item Content
1
TOTAL COUNTER
Total counter
2
MAINTENANCE COUNTER
Maintenance counter
Item Content Setting range Default
1
SINGLE COUNT
Single count
1-2 2
2
DOUBLE COUNT
Double count
26-6
Purpose Setting
Function
(Purpose)
Used to set the specifications depending on the
destination.
Item Specifications Destination
Item Content
Setting
range
Default
0
JAPAN
Japan
0-14 0
1
SEC
SEC
2
SECL
SECL
3
SEEG
SEEG
4
SUK
SUK
5
SCA
SCA
6
SEF
SEF
7
INEG
EX inch series
8
ABEG
EX AB series
9
INEF
EX inch series (FC)
10
ABEF
EX AB series (FC)
11
CHINESE
China
12
TAI WA N
Taiwan AB
13
SEEG2
SEEG2
14 TAIWAN2 Taiwan China
To Next Page
