MX-M260/M310/M260N/M310N SIMULATION 6 - 38
Note: Executable only when the FAX is installed.
Operation/procedure
Select the signal number with the 10-key, and press the [START] key.
By setting the signal number, signals are sent to the line and the
machine speaker. (Sending signals is continued until interruption com-
mand is made (by pressing [SYSTEM SETTINGS] key.)
By entering the signal number and pressing the [START] key during
execution, the signal kind can be changed.
Note: Executable only when the FAX is installed.
Operation/procedure
Press the [START] key.
The confidential ID table (confidential BOX numbers, confidential BOX
names, and confidential password) is printed.
The confidential data of My company mode is printed separately.
Note: Executable only when the FAX is installed.
Operation/procedure
Press the [START] key.
Used to input all image data (including confidential reception data,
remote send image, not-sent image) stored in image memory of the
FAX section.
The output image is remained even after outputting.
Note: Executable only when the FAX is installed.
14 4.8 V34 4.8 V34
15 2.4 V34 2.4 V34
16 14.4 V33 14.4 V33
17 12.0 V33 12.0 V33
18 14.4 V17 14.4 V17
19 12.0 V17 12.0 V17
20 9.6 V17 9.6 V17
21 7.2 V17 7.2 V17
22 9.6 V29 9.6 V29
23 7.2 V29 7.2 V29
24 4.8 V27t 4.8 V27t
25 2.4 V27t 2.4 V27t
26 0.3 FLG 7EH Flag signal
27 CED2100
Tone signal
28 CNG1100
29 0.3 V21
30 ANSam
31 RINGER
Pseudo-ringer sound
([ON HOOK] key ON)
32 No MSG
Voice message (no sound)
Under the state where the ring back tone can be
sent to the line, keep the sound composition IC
volume to 0.
33 No RBT
Ring back tone (no sound)
Under the state where the ring back tone can be
sent to the line, keep the G/A volume to 0.
34 DP MAKE
Dial pulse (make)
Maintain the make state with keeping the condition
to be able to send to the dial pulse line.
35 DP BRK
Dial pulse (break)
Maintain the break state with keeping the condition
to be able to send to the dial pulse line.
66-5
Purpose Operation test/check
Function
(Purpose)
Signal send mode (Signal send level soft SW setting)
Section FAX
Item Operation
Signal number Send signal
1 NO SIGNAL Signal not sent
2 33.6 V34 33.6 V34
3 31.2 V34 31.2 V34
4 28.8 V34 28.8 V34
5 26.4 V34 26.4 V34
6 24.0 V34 24.0 V34
7 21.6 V34 21.6 V34
8 19.2 V34 19.2 V34
9 16.8 V34 16.8 V34
10 14.4 V34 14.4 V34
11 12.0 V34 12.0 V34
12 9.6 V34 9.6 V34
13 7.2 V34 7.2 V34
14 4.8 V34 4.8 V34
15 2.4 V34 2.4 V34
Item Send signal
16 14.4 V33 14.4 V33
17 12.0 V33 12.0 V33
18 14.4 V17 14.4 V17
19 12.0 V17 12.0 V17
20 9.6 V17 9.6 V17
21 7.2 V17 7.2 V17
22 9.6 V29 9.6 V29
23 7.2 V29 7.2 V29
24 4.8 V27t 4.8 V27t
25 2.4 V27t 2.4 V27t
26 0.3 FLG 7EH Flag signal
27 CED2100
Tone signal
28 CNG1100
29 0.3 V21
30 ANSam
31 RINGER
Pseudo-ringer sound
([ON HOOK] key ON)
32 No MSG
Voice message (no sound)
Under the state where the ring back tone can be
sent to the line, keep the sound composition IC
volume to 0.
33 No RBT
Ring back tone (no sound)
Under the state where the ring back tone can be
sent to the line, keep the G/A volume to 0.
34 DP MAKE
Dial pulse (make)
Maintain the make state with keeping the condition
to be able to send to the dial pulse line.
35 DP BRK
Dial pulse (break)
Maintain the break state with keeping the condition
to be able to send to the dial pulse line.
66-6
Purpose Data output, check
Function (Purpose) Printing the confidential password
Section FAX
Item Data Confidential/Pass code
66-7
Purpose Data output, check
Function (Purpose) Print the screen memory contents
Section FAX
Item Data Image data
Signal number Send signal
