CHANGING THE PRELOAD OF THE SHOCK
Remove and clean the rear shock unit (
☛
p.108).
Loosen the locking nut
1
.
Loosen / tighten the adjusting nut
2
depending
on the length required..
Indications
Loosening
one turn
Decreases the ove-
rall length by 3mm.
Tightening
one turn
Increases the overall
length by 3mm.
Tighten the locking nut
1
.
Reinstall the shock (
☛
p.109)
Recheck the settings (
☛
p.98)
CHANGING THE SHOCK SPRING
Remove and clean the rear shock unit (
☛
p.108)
Select and install a spring based on your weight.
Spring Rate
Rider Weight (with equipment) : 65-75kg 48N/mm
Rider Weight (with equipment) : 75-85kg 51N/mm
Rider Weight (with equipment) : 85-95kg 54N/mm
Reinstall the shock.
Adjust the sag (
☛
p.98)
Adjust the static deflection (
☛
p.98)
99
