10
006X
Order Disassemble Parts Name
9 Return pipe
10 Injection nozzle · Gasket
11 Oil transfer pipe · Eye bolt · Seal washe
12 Connector · Glow plug
13 Oil pressure switch
14 Thermostat case · Gasket
15 Head cover · O-Ring · Intake manifold · Spacer
16 Rocker arm assembly · O-Ring · Cap
NOTE: Remove the caps from intake valves and exhaust valves.
17 Push rod
18 Cylinder head assembly · Head gasket
NOTE:
1. Untighten the cylinder head bolts in several steps and remove the cylinder head assembly.
19 Tappet
To Next Page
