11
007X
Order Disassemble Pats Name
20 V-belt · Cooling fan · Fan holder · Fan pulley
21 Water pump assembly · Gasket
22 Crankshaft pulley
23 Hydraulic oil pump, Cover, Drain cock.
24 Timing gear case assembly · Gasket
NOTE: Remove the engine stop solenoid and injection pump assembly at first.
25 Idle gear · Oil pump assembly
26 Cam shaft assembly · Plate
NOTE: Remove the bolts and plate at first, and draw out the cam shaft assembly.
27 Front plate · Gasket
