Reassembly
(1) Install the metal with oil groove to the upper bearing
holder and the metal without oil groove to the lower
bearing holder
(2) With the stepped area of the bearing holder facing the
front side, install the bearing holder to be fitted with
thrust washer on the flywheel side and the bearing
holder with identification cutting mark at the center.
Bearing holder tightening torque
49 – 53.9 N·m
{5 – 5.5 kgf·m}
(3) Install the thrust washer facing the oil groove towards
the crankshaft thrust surface.
NOTE: Be sure to confirm that the oil hole of the
bearing holder and that of the cylinder
block are in the same direction.
035X
