7) Troubleshooting
(1) Pinion does not advance even though the key switch is turned ON.
Unit Cause Remedy
Wiring
Disconnected wire, untightened battery and switch terminals, or
improper contact of the inserting part.
Correct and retighten
Key switch Improper contact preventing flow of current.
Correct or replace the contact
part
Starting motor
Helical spline of the pinion shaft is scored and prevents the pinion
from moving.
Replace or correct
Magnet switch
Improper movement of the plunger of the magnet switch or
disconnected wire or short circuit of the coil.
Correct or replace
(2) Though the pinion is engaged and the motor rotates, the rotation is not transmitted to the engine.
Unit Cause Remedy
Starting motor
Defective clutch.
Broken reduction gear.
Replace
Replace
(3) Though the pinion is engaged with the ring, the starting motor does not start.
Unit Cause Remedy
Wiring
Disconnected wire, connecting the battery and magnet switch.
Insufficient tightening of the lead wire connecting the magnet switch
and motor.
Repair, retightening, or
replace the wire.
Starting motor
Locked ball bearing.
Improper installation.
Worn out brush, improper contact of brush spring.
Stained commutator.
Defective armature or field coil.
Insufficient tightening of connections of the field coil and brush.
Replace
Install properly.
Replace
Correct
Correct or replace
Retighten
Magnet switch
Broken holding coil
Improper contact of contact
Roughened contact surface of contact
Replace
Replace
Replace
Battery Discharged Charge
(4) Motor starts rotating before the pinion is engaged with the ring gear.
Unit Cause Remedy
Starting motor
Improper sliding of pinion shaft
Worn out pinion tooth top
Improper pinion pushing position
Replace
Correct
Replace
Engine Worn out ring gear Replace
Magnet switch Defective magnet switch Replace
