Multi-speed parameter group 04
PARAMETER DESCRIPTION 99
5.5.1 16 speeds
 With the combination of digital input terminal RL, RM, RH and REX, selects speed operation (the most are 16
speeds in total)
Parameter
Name
Factory
Value
Setting Range
Content
04-00
P.4
Speed1(high speed)
60.00Hz
0～650.00Hz
---
04-01
P.5
Speed2
(medium speed)
30.00Hz
0～650.00Hz
---
04-02
P.6
Speed3(low speed)
10.00Hz
0～650.00Hz
---
04-03
P.24
Speed4
99999
0～650.00Hz
---
99999
99999: Function invalid
04-04
P.25
Speed5
99999
Same as 04-03
Same as 04-03
04-05
P.26
Speed6
99999
Same as 04-03
Same as 04-03
04-06
P.27
Speed7
99999
Same as 04-03
Same as 04-03
04-07
P.142
Speed8
99999
0～650.00Hz
---
04-08
P.143
Speed9
99999
Same as 04-03
Same as 04-03
04-09
P.144
Speed10
99999
Same as 04-03
Same as 04-03
04-10
P.145
Speed11
99999
Same as 04-03
Same as 04-03
04-11
P.146
Speed12
99999
Same as 04-03
Same as 04-03
04-12
P.147
Speed13
99999
Same as 04-03
Same as 04-03
04-13
P.148
Speed14
99999
Same as 04-03
Same as 04-03
04-14
P.149
Speed15
99999
Same as 04-03
Same as 04-03
16 speeds

If all the set values of 04-03~04-06 and 04-07~04-14 are not 99999, “16-speed operation” is active. It means that
with the combination of RL, RM, RH and REX, there are 16 speeds in total. For setting up the target frequency of
the inverter, please refer to the figure below:
Setting
