Digital input/ output parameter group03
PARAMETER DESCRIPTION 89
5.4.1 Function selection of digital input
 Use the following parameters to select or change the digital input terminal functions. Any function from 0 to 45 can
be selected by each terminal (Note 1).
Parameter
Name
Factory
Value
Setting Range
Content
03-00
P.83
STF function selection
0
0
STF(the inverter runs forward)
1
STR(the inverter runs reverse)
2
RL(Multi-speed low speed)
3
RM(Multi-speed medium speed)
4
RH(multi-speed high speed)
5
Reserved
6
The external thermal relay operation
7
MRS(the instantaneous stopping of the inverter output)
8
RT(the inverter second function)
9
EXT(external JOG)
10
STF+EXJ
11
STR+EXJ
12
STF+RT
13
STR+RT
14
STF+RL
15
STR+RL
16
STF+RM
17
STR+RM
18
STF+RH
19
STR+RH
20
STF+RL+RM
21
STR+RL+RM
22
STF+RT+RL
23
STR+RT+RL
24
STF+RT+RM
25
STR+RT+RM
26
STF+RT+RL+RM
27
STR+RT+RL+RM
28
RUN(the inverter runs forward)
29
STF/STR(it is used with RUN, when STF/ STR is “on”, the
inverter runs reverse；when STF/STR is “off”, the inverter
runs forward)
30
RES(external reset function)
31
STOP(it can be used as a three-wire mode with the RUN
signal or the STF-STR terminal)
32
REX(multi-speed set (16 levels))
33
PO(in “external mode", programmed operation mode is
chosen)
