Communication parameter group07
PARAMETER DESCRIPTION 117
5.8 Communication parameter group 07
Group
Parameter
Number
Name
Setting Range
Factory
Value
Pag
e
07-00
P.33
Communication
protocol selection
0: Modbus protocol
1
116
1: Shihlin protocol
07-01
P.36
Inverter station
number
0～254
0
116
07-02
P.32
Serial
communication
Baud rate
selection
0: Baud rate:4800bps
1
116
1: Baud rate:9600bps
2: Baud rate:19200bps
3: Baud rate:38400bps
4: Baud rate:57600bps
5: Baud rate:115200bps
07-03
P.48
Data length
0: 8bit
0
116
1: 7bit
07-04
P.49
Stop bit length
0: 1bit
0
116
1: 2bit
07-05
P.50
Parity check
selection
0: No parity verification
0
116
1: Odd
2: Even
07-06
P.51
CR/LFselection
1: CR only
1
116
2: Both CR and LF
07-07
P.154
Modbus
communication
format
0: 1, 7, N, 2 (Modbus, ASCII)
4
116
1: 1, 7, E, 1 (Modbus, ASCII)
2: 1, 7, O, 1 (Modbus, ASCII)
3: 1, 8, N, 2 (Modbus, RTU)
4: 1, 8, E, 1 (Modbus, RTU)
5: 1, 8, O, 1 (Modbus, RTU)
07-08
P.52
Number of
communication
retries
0～10
1
116
07-09
P.53
Communication
check time interval
0～999.8s: Use the set value for the communication overtime
test.
99999
116
99999: No communication overtime test.
07-10
P.153
Communication
error handling
0: Warn and call to stop
0
116
1: No warning and keep running
07-11
P.34
ComunicationEEP
ROM writing
selection
0: Write parameters in communication mode, write into RAM
and EEPROM
0
132
1: Write parameters in communication mode, write intoonly
RAM
