Appendix 1 Parameter table
APPENDIX 166
7. APPENDIX
7.1 Appendix 1 Parameter table
Parameter
Number
Group
Name
Setting Range
Factory
Value
Page
P.0
01-10
Torque boost
0.2～0.75K types: 0～30.0%
6.0%
47
1.5K～3.7K types: 0～30.0%
4.0%
5.5K types: 0～30.0%
3.0%
P.1
01-00
Maximum frequency
0.00～01-02(P.18)Hz
120HZ
62
P.2
01-01
Minimum frequency
0～120.00Hz
0.00Hz
62
P.3
01-03
Base frequency
50Hz system setting: 0～650.00Hz
50.00Hz
63
60Hz system setting: 0～650.00Hz
60.00Hz
P.4
04-00
Speed1(high speed)
0～650.00Hz
60.00Hz
97
P.5
04-01
Speed2(medium speed)
0～650.00Hz
30.00Hz
97
P.6
04-02
Speed3(low speed)
0～650.00Hz
10.00Hz
97
P.7
01-06
Acceleration time
3.7K and types below: 0～360.00s/0～3600.0s
5.00s
64
5.5K types: 0～360.00s/0～3600.0s
10.00s
P.8
01-07
Deceleration time
3.7K and types below: 0～360.00s/0～3600.0s
5.00s
64
5.5K types: 0～360.00s/0～3600.0s
10.00s
P.9
06-00
Electronic thermal relay
capacity
0~500.00A
According
to type
109
P.10
10-00
DC injection brake
operation frequency
0～120.00Hz
3.00Hz
142
P.11
10-01
DC injection brake
operation time
0～60.0s
0.5s
142
P.12
10-02
DC injection brake
operation voltage
0～30.0%
4.0%
142
P.13
01-11
Starting frequency
0～60.00Hz
0.50Hz
66
P.14
01-12
Load pattern selection
0: Applicable to constant torque loads (convey
belt, etc.)
0
67
1: Applicable to variable torque loads (fans and
pumps, etc.)
2, 3: Applicable to ascending / descending loads.
4: Multipoint VF curve.
5～13: Special two-point VF curve.
P.15
01-13
JOG frequency
0～650.00Hz
5.00Hz
69
P.16
01-14
JOG acceleration/
deceleration time
0～360.00s/0～3600.0s
0.50s
69
