Basic operation procedures for different modes
PRIMARY OPERATION 39
4.3.6 Basic operation procedures for combined mode 2 (00-16(P.79)＝5)
• In Combined Mode 2, indicating lamp will light up.
Note: For selecting and switching the operation mode, please refer to Section4.2.
• The target frequency is set by the external terminals (the default priority is from high to low):
• If the programmable operating mode is chosen, please refer to Section5.4.1 Function selection of digital input and 5.5.2
Programmed operation mode.
• If the target frequency is set by multi-speed stage levels, please refer to 04-00(P.4) in Chapter 5..
• If the target frequency is set by the input signal across terminal 3-5, please refer to 02-21(P.39) in Chapter 5.
• Press or of operation panel to run the motor. At this point, indicating lamp will light up,
indicating that the motor is running.
Note: 1.For detailed operation flow for the monitor mode, please refer to Section4.2.3.
2. While the motor is running, the user can enter into the frequency setting mode to change the target frequency for
regulating the motor speed.
•
Press and the motor will begin to decelerate until it comes to a full stop.
• Indicating lamp will not turn off until the inverter stops the output.
