Multi-speed parameter group 04
PARAMETER DESCRIPTION 101
5.5.2 Programmed operation mode
 The application of this parameter can be used as the operation process control for general small machinery, food
processing machinery and washing equipment, which can replace some traditional relays, switches, timer and
other control circuit, etc.
Parameter
Name
Factory
Value
Setting Range
Content
04-15
P.100
Minute/second selection
1
0
The minimum increment of run time is 1 minute.
1
The minimum increment of run time is 1 second.
04-16
P.121
Run direction in each
section
0
0～255
0～255
04-17
P.122
Cycle selection
0
0
0: Cycle function invalid
1～8
Run circularly from the setting section.
04-18
P.123
Acceleration/deceleration
time setting selection
0
0
The acceleration time is set by 01-06(P.7); the deceleration
time is set by 01-07(P.8).
1
The acceleration and deceleration time is both determined
by 04-35(P.111)～04-42(P.118).
04-19
P.131
Programmed operation
mode speed 1
0.00Hz
0～650.00Hz
---
04-20
P.132
Programmed operation
mode speed 2
0.00Hz
0～650.00Hz
---
04-21
P.133
Programmed operation
mode speed3
0.00Hz
0～650.00Hz
---
04-22
P.134
Programmed operation
mode speed 4
0.00Hz
0～650.00Hz
---
04-23
P.135
Programmed operation
mode speed 5
0.00Hz
0～650.00Hz
---
04-24
P.136
Programmed operation
mode speed 6
0.00Hz
0～650.00Hz
---
04-25
P.137
Programmed operation
mode speed 7
0.00Hz
0～650.00Hz
---
04-26
P.138
Programmed operation
mode speed 8
0.00Hz
0～650.00Hz
---
04-27
P.101
Programmed operation
mode speed 1 operating
time
0.0s
0～6000.0s
---
04-28
P.102
Programmed operation
mode speed 2 operating
time
0.0s
0～6000.0s
---
04-29
P.103
Programmed operation
mode speed3 operating
time
0.0s
0～6000.0s
---
04-30
P.104
Programmed operation
mode speed 4 operating
time
0.0s
0～6000.0s
---
