General specification
MANUAL GUIDE 12
3.2 General specification
Control method
SVPWM control, V/F control,General magnetic vector control
Output frequency range
0~650.00Hz
Frequency
setting
resolution
Digital setting
The frequency is set within 100Hz, the resolution is 0.01Hz.
The frequency is set more than100Hz, the resolution is 0.1Hz.
Analog setting
DC 0~5V or 4~20mA signal, 11 bit.
DC 0~10V signal, 12 bit.
Output
frequency
accuracy
Digital setting
Maximum target frequency±0.01%.
Analog setting
Maximum target frequency±0.1%.
Start torque
180% 3Hz, 200% 5Hz：Under the condition of general magnetic vector control
V/Fcharacteristics
Constant torque curve, variable torque curve, five-point curve
Acceleration / deceleration curve
characteristics
Linear acceleration /deceleration curve, S pattern acceleration /deceleration curve1 & 2 & 3
Drive motor
Induction motor(IM)
Stalling protection
The stalling protection level can be set to 0~250 %( 06-01(P.22)). The default value is 200%.
Target frequency setting
Operation panel setting, DC 0~5V/10V signal, DC 4~20 mA signal, multiple speed stage level
setting, communication setting.
Operation
panel
Operation
monitoring
Output frequency, output current, output voltage, PN voltage, electronic thermal accumulation
rate, temperature rising accumulation rate, output power, analog value input signal, output
terminal status…; alarm history 12 groups at most, the last group of alarm message is recorded.
LED indication lamp
(6)
frequency monitoring indication lamp, voltage monitoring indication lamp, current monitoring
indication lamp, motor operation lamp, mode switchinglamp, PUcontrolindication lamp
Communication function
RS-485 communication can select Shihlin/Modbus communication protocol, communication
speed115200bps or lower.
Protection mechanism /
alarm function
Output short circuit protection, Over-current protection, over-voltage protection, under-voltage
protection, motor over-heat protection (06-00(P.9)), IGBT module over-heat protection,
communication abnormality protection…
Environment
Ambient temperature
-10 ~ +50℃ (non-freezing)
Ambient humidity
Below 90%Rh (non-condensing).
Storage temperature
-20 ~ +65℃.
Surrounding environment
Indoor, no corrosive gas, no flammable gas, no flammable powder.
Altitude
Altitude below 2000 meters, whenaltitude is above 1,000 m,derate
the rated current 2% per 100 m
Vibration
Vibration below 5.9m/s
2
(0.6G).
Grade of protection
IP20
The degree of
environmental pollution
II
environmental pollution
degree
2
Class of protection
Class I
International certification
CE
