Shihlin electric SC3-043-2.2K User Manual

Nameplate instruction
DELIVERY CHECK9
3. INVERTER INTRODUCTION
3.1 Electric specification
3.1.1 440V series three-phase
Frame
A
B
Model SC3-043-□□□K-□□
0.4
0.75
1.5
2.2
3.7
5.5
Output
Ratedoutput capacity (kVA)
1
2
3
4.6
6.9
9.2
Rated output current(A)
1.5
2.6
4.2
6
9
12
Applicable motor capacity (HP)
0.5
1
2
3
5
7.5
Applicable motor capacity (kW)
0.4
0.75
1.5
2.2
3.7
5.5
Overload current rating
150% 60seconds 200% 1 second inverse time characteristics
Carrier frequency (kHz)
1~15kHz
Maximum output voltage
Three-phase 380-480V
Power
supply
Rated power voltage
Three-phase 380-480V 50Hz / 60Hz
Power voltagepermissible
fluctuation
Three-phase 323-528V 50Hz / 60Hz
Power frequency permissible
fluctuation
±5%
Power source capacity (kVA)
1.5
2.5
4.5
6.9
10.4
11.5
Cooling method
Self cooling
Forced air cooling
Inverter weight (kg)
0.74
0.74
0.81
1.37
1.37
1.42

Shihlin electric SC3-043-2.2K Specifications

General

Brand	Shihlin electric
Model	SC3-043-2.2K
Category	Inverter
Language	English
