Protection parameter group06
PARAMETER DESCRIPTION 106
5.6.1 Motor parameter auto-tuning function selection
 Via accurate motor parameter auto-tuning function, realizes motor high-performance vector control.
Parameter
Name
Factory
Value
Setting Range
Content
05-00
P.301
Motor parameter
auto-tuning function
selection
0
0
Parameter auto-tuning function with no motor
1
Induction motor parameter auto-tuning measuring the
running motor
2
Induction motor parameter auto-tuning measuring the
stopped motor
3
Induction motor online auto-tuning function
Motor parameter auto-tuning function

When 00-21=0, no motor parameter auto-tuning function is required for normal V/F curve operation.

For IM general magnetic vector control please set 00-21 to 2. The frequency will be altered due to elevated voltage
and increased compensatory motor load.

For executing the IM motor parameter auto-tuning function, set 05-00 to 1 or 2 and press the forward rotation or
the reverse rotation key. During the measuring process, the operation panel will flicker and display “TUN”. If the
measurement fails, the operation panel will flicker “FAL” for three seconds and then return to normal display.

Procedures for IM motor parameter auto-tuning are presented below:
