System parameter group00
PARAMETER DESCRIPTION 59
General magnetic vector control of induction motor: The voltage boost, the frequency changes when
compensation motor load increases.
Note: 1. Motor capacity shall be same level or lower level with inverter capacity.
2. When making automatic measurement, such as allowing the motor rotation, please set the P.301 = 1 (dynamic
measurement), the load and the motor must be made out completely. Such as load environment don't allow
Auto - tuning automatically measure when motor rotate, please set the P. 301 = 2 (static measurement).
3. Domestic magnetic to quantity control: According to function of the automatic measurement (Auto - tuning) to
enhance the control performance.
5.1.12 50/60Hz switch selection
According to different power frequency and the default motor frequency, frequency-related parameters which are
50Hz or 60Hz can be selected.
Parameter
Name
Factory
Value
Setting Range
Content
00-24
P.189
50/60Hz switch
selection
0
0
The frequency parameter default value is 60Hz system.
1
1
The frequency parameter default value is50Hz system.
50/60Hz switch selection
If the customer would like to set frequency related parameter to 60Hzsystem (00-24=”0”), please follow the
following two steps.
1. Set 00-24=0;
2. Set 00-02 to the factory default value (at this point, frequency-related parameters of the inverter will be reset to 60Hz.
The affected parameters are as follows:
Group
No.
Name
Group
No.
Name
01-03
P.3
Base frequency
05-04
P.305
Motor rated frequency
01-09
P.20
Accelerate/decelerate reference
frequency
05-06
P.307
Motor rated rotation speed
06-03
P.66
Stall prevention operation reduction
starting frequency
02-21
P.39
The maximum operation frequency of
terminal 3-5
08-14
P.182
Integral upper limit
Setting
