Digital input/ output parameter group03
PARAMETER DESCRIPTION 87
when the alarm goes off.)
Group
Parameter
Number
Name
Setting Range
Factory
Value
Page
03-00
P.83
STF function selection
35: MPO (in “external mode” the manually
operation cycle mode is chosen.)
0
87
36: TRI(triangle wave function is chosen)
37: Reserved
38: Reserved
39: STF/STR +STOP (The motor has a reverse
rotation when the RUN signal is on. When the
RUN signal is off, stop the motor and then run
the motor for forward rotation.
40: P_MRS (the inverter output instantaneously
stops, The MRS is pulse signal input)
42: Reserved
43: RUN_EN (the digital input terminal running
enable)
44: PID_OFF (the digital input terminal stopping
PID enable)
45: The second mode
03-01
P.84
STRfunction selection
Same as 03-00
1
88
03-03
P.80
M0 function selection
Same as 03-00
2
88
03-04
P.81
M1 function selection
Same as 03-00
3
88
03-11
P.85
A-C function selection
0: RUN(inverter running)
5
90
1: SU(reaching the output frequency)
2: FU(output frequency detection)
3: OL(overload detection)
4: OMD(zero current detection)
5: ALARM(alarm detection)
6: PO1(programmed operation section detection)
7: PO2(programmed operation periodical
detection)
8: PO3(programmed operation pause detection)
9: Reserved
10:Reserved
11: OMD1(zero current detection)
12: OL2 (Over torque alarm output)
13～16: Reserved
17: RY(the accomplishment of inverter running
preparation)
18: Maintenance alarm detection
