- 8 -
Name Function
h
Operating keys
(1) (parameter) key
• Pressing this key on any screen calls the next screen onto display.
• Pressing this key continuously for 3 seconds calls the initial screen of screen group 5.
(2) (up) key
• Used to increase a numerical value on a numerical value setting screen.
• Used to select an item on an item selection screen.
(3) (down) key
• Used to decrease a numerical value on a numerical value setting screen.
• Used to select an item on an item selection screen.
(4) (entry) key
• Used to register a set data changed by means of the or key on each screen (the decimal
point of the rightmost digit goes out).
• When pressed for 3 seconds continuously on output (OUT) screen, this key switches between
automatic output and manual output.
(5) (group) key
• When pressed in the middle of setting in screen groups 1, 3, 4 or 5, the initial screen of the group is
called onto display.
• When pressed in the screen group 2, the initial screen of screen group 1 is called onto display.
• When pressed on the basic screen, the display moves to screen group 1, screen group 3, screen
group 4 and the basic screen in the order mentioned.
• When pressed on the initial screen of screen group 5, the basic screen is called.
(6) (pattern) key
• When pressed during stop (RST) on the basic screen, a starting pattern can be selected. It is
registered by pressing the key
• This key is used to move to other screen groups. For details, see Section 5-1 or 5-5.
(7) (step) key
• This key is used to move to other screen groups. For details, see Section 5-1 or 5-5.
(8) (run/reset) key
• When pressed continuously for 3 seconds on the basic screen, execution (RUN) and stop (RST) are
switched.
• When pressed in any of screen groups 1 - 5, the preceding screen is returned onto display.
To Next Page
