6.1 Specifications
Mobile DaRt Installation Manual
6-5
CXDI-50G
CXDI
Effective range 35 x 43 cm
Effective Number of Pixels 2208 x2688
Pixel Pitch 160µm x 160µm
Imaging Unit mass 4.8kg (except Grid)
Mechanical strength Load uniformly: 150kg
Load partly: 100kg/
φ
40mm
Mass 4.8 kg (Except cable)
Attenuation equivalent of front panel 0.2mmAl.Eq.
Maximum irradiation time 1000msec
Dimension 491(W) x 477(D) x 23(H)mm with operation grip
Grayscale 12bit (4,096 grayscale)
Option
Grid Attenuation equivalent:2.3mmAl.Eq.
For detail about CXDI, please refer to CXDI series operation manual (Canon CXDI Digital Radiography).
Options
MUX-100D MUX-100DJ
Remote controller
Infrared type
Ready operation, X-ray operation, Collimator lamp ON/OFF
Removable X-ray protective screen Removable X-ray protective acrylic screen
Dose Area Meter Indicates the dose area,product.
Grid Refer to CXDI manual
