3.2 Unpacking
Mobile DaRt Installation Manual
3-3
3.2 Unpacking
CAUTION
Check the shock detectors on the imaging unit.
Make sure there is no damage on the package before opening
CXDI-50G. Do not drop or shock the package.
The imaging unit is equipped with four shock detectors. This detector is
normally white, and an excessive shock will cause it to change color. If
the shock detector changes color, there is a chance the imaging unit is
damaged or broken.
Make sure the following items are packed together:
Part number Quantity Description
MUX-100D 503-61000-01
MUX-100DJ 503-61000-04
1
Arm cover 503-47619
503-47620
1
1
Screws are attached on
the tap hole on the arm
and arm cover.
Spare parts 502-21566
1
Including 46 pieces of
screw caps (5 pieces are
the reserves.)
Operation manual M503-1028 1
MUX main
unit
Installation manual M503-2008 1
Imaging unit 1
Make sure that the color
of shock detectors has
not changed.
X-Ray I/F Cable 1
Power Cable 1
Power Box 1
Sensor information
file FD
1
Remote switch 1 Not used.
CXDI application
software
1
CXDI-50G
Components
Manual 1 set
For CXDI-50G, refer to Canon manual.
Remote controller 502-21343-06
Protection screen 503-50338-01
Dose area meter 503-63066
503-63066-01 (UL)
CXDI-50G grid unit (r10, N40, f
0
180)
CXDI-50G grid unit (r8, N40, f
0
110)
CXDI-50G grid unit (r6, N40, f
0
150)
Options
CXDI-50G grid unit (r4, N40, f
0
110)
