Appendix F Operation of High-Voltage Cable
Mobile DaRt Installation Manual
F-ii
F.1 Spare parts with high-voltage cable
Spare parts of the X-ray tube assembly side mini-plug.
Following parts are included in the ”Mini-plug spare parts kit “(P/N
511-15061-13).
Silicon Rubber jacket 5pc
Silicon washer 5pc
Silicon Oil 5pc
Spare parts of the high-voltage generator side plug.
Contact pin P/N 511-15061-11 (Contact pin + tool)
Silicon packing P/N 532-23029 (3mm thickness)
P/N 532-23061 (2mm thickness)
Please use silicon packing that the thickness is thin (2mm thickness) when you
use the tube voltage meter.
CAUTION
Please exchange the silicon packing, the silicon Rubber jacket and the
silicon washer every year. However, please exchange these silicon
parts when you remove the cable by the repair, check etc.
CAUTION
Please use only a specified silicone oil for the X-rax tube assembly side.
Do not use silicon grease.
