4.24 Removement of 50G and Power Box from MUX-100D
Mobile DaRt Installation Manual
4-43
4.24 Removement of 50G and Power Box from
MUX-100D
CXDI-50G is separated from MUX-100D according to the following
procedures.
1. The main breaker is turned off.
2. Open the cover (both Side cover, Upper cover, cable cover, and FPD box).
3. CXDI-50G is detached from MUX-100D according to the procedure from 8
to 2 of the clauses “4.3 Assemble for the CXDI-50G”.
4. The covers are attached.
4.25 Packing and sending MUX-100D and 50G
1. CXDI-50G is packed to the packing box of CXDI-50G.
2. MUX-100D is packed.
3. CXDI-50G and MUX-100 are send.
4.26 Adjustment of Image quality
Adjust of image quality refer to CANON Inc. CXDI manual and MLT
manual.
・Linearity check of Transfer Image Density.
・Operation Unit Gamma correction.
