E.6 Centering the Collimator and X-Ray Focus
Mobile DaRt Installation Manual
E-xv
Because the center of the collimator blades and the illumination field center
are aligned each other using a dedicated device in factory assembling,
never move the lamp mounting board.
Fig. 8 Adjust field center
Fig. 9 How to adjust center
CAUTION
Cassette
Lamp field
Solder
Center of lamp field
Center of X-ray field
Screw
Bolt Collimator
Center of Collimator X-ray focus
X-ray beam axis
Move Collimator
Center of lamp field (Center of leaves) Center of X-ray field
To Next Page
