Operating Instructions Chapter 7
C 4000
38 © SICK AG • Safety Systems • Germany • All rights reserved 8 009 221/16-11-00
Configuration
7 Configuration
7.1 Delivery status
When delivered, the C 4000 is configured ready for protective operation.
· Machine-side restart interlock
· No external device monitoring (EDM)
· No beam coding
· No blanking
· Small scanning range (0-2.5 m or 0-6 m)
7.2 Preparing the configuration
How to prepare the configuration:
> Make sure that the safety light curtain has been properly mounted and that the electrical
connections are correct and in place.
> Plan all required settings (operating mode, beam coding, resolution, cascading, etc.)
To configure the safety light curtain, you need:
· CDS (Configuration & Diagnostic Software) on CD-ROM
· User manual for CDS on CD-ROM
· PC/Notebook with Windows 9x/NT 4/2000 and a serial interface (RS 232).
PC not included.
· Connecting cable between PC and C 4000
> To configure the device, please read the user manual for the CDS (Configuration & Diag-
nostic Software) and use the online help function of the programme.
