11.5 Deflector mirror
11.5.1 Deflector mirror PNS 80 for protective field width 0 … 4 m (total)
Dimensional drawings, see figure 33 on page 51
11.5.2 Deflector mirror PNS 120 for protective field width 4 … 15 m (total)
Dimensional drawings, see figure 33 on page 51
Protective field height [mm] Type number Part number
300
PNS 80-034 1 013 731
450
PNS 80-049 1 011 132
600
PNS 80-064 1 013 732
750
PNS 80-079 1 013 733
900
PNS 80-094 1 013 734
1050
PNS 80-109 1 013 735
1200
PNS 80-124 1 013 736
1350
PNS 80-139 1 013 737
1500
PNS 80-154 1 013 738
1650
PNS 80-169 1 013 739
1800
PNS 80-184 1 013 740
Protective field height [mm] Type number Part number
300
PNS 120-034 1 013 751
450
PNS 120-049 1 011 146
600
PNS 120-064 1 013 752
750
PNS 120-079 1 013 753
900
PNS 120-094 1 013 754
1050
PNS 120-109 1 013 755
1200
PNS 120-124 1 013 756
1350
PNS 120-139 1 013 757
1500
PNS 120-154 1 013 758
1650
PNS 120-169 1 013 759
1800
PNS 120-184 1 013 760
T
a
b
.
28
:
P
art num
b
ers,
deflector mirror PNS 80
T
a
b
.
29
:
P
art num
b
ers,
deflector mirror PNS 120
