SICK C 4000 Series User Manual

Operating Instructions Chapter 10
C4000
Technical specifications
8 009 221/16-11-00 © SICK AG • Safety Systems • Germany • All rights reserved 43
10 Technical specifications
10.1 Data sheet
minimum typical maximum
General system data
Protective field height, depending
on type
300 mm to 1800 mm
Resolution, depending on type 14 mm to 40 mm
Protective field width
Resolution 14 mm 0 m 6 m
Resolution 20, 30 or 40 mm 0 m 19 m
Protection class (VDE 106) III
Enclosure rating IP 65
Supply voltage U
V
at appliance
1)
19.2 V 24 V 28.8 V
Residual ripple
2)
±10%
Synchronisation Optical, without separate synchronisation
Safety category (EN 61496) Type 4
ON time after applying the supply
voltage of sender and receiver
8s
Sender unit
Test input
Input resistance (High) 10 kW
Sender inactive (test) –1 V 0 V 5 V
Sender active (High) 15 V 24 V 28.8 V
Response time to test Depending on number of beams
Wavelength of sender 940 nm
Power consumption 2 A (host/
guest/guest)
Weight Depending on protective field height (see page 47)
Receiver unit
Switching outputs (OSSDs) 2 PNP semiconductor, short-circuit protected
3)
,
cross-circuit monitored
Switching voltage HIGH active
(U
eff
)
4)
15 V 24 V 28.8 V
Switching voltage LOW 0 V 0 V 3.5 V
Switching current 500 mA
Leakage current
5)
0.25 mA
Load capacity 2.2 mF
Switching sequence Depending on load inductance
Load inductance
6)
2.2 H
Test pulse data
7)
Test pulse width 120 ms 150 ms 300 ms
Test pulse rate 3
1
/s 5
1
/s 10
1
/s
Tab. 15: Technical
s
pecifications C 4000
