Technical specifications
Protective field height
[mm]
Number of beams for physical resolution
14 mm 20 mm 30 mm 40 mm
300
40 30 15 10
450
60 45 23 15
600
80 60 30 20
750
100 75 38 25
900
120 90 45 30
1050
140 105 53 35
1200
160 120 60 40
1350
180 135 68 45
1500
200 150 75 50
1650
220 165 83 55
1800
240 180 90 60
Number of beams Without beam coding With beam coding
10
9ms 11ms
15
10 ms 12 ms
20
10 ms 13 ms
23
10 ms 14 ms
25
10 ms 14 ms
30
11 ms 15 ms
35
11 ms 16 ms
38
11 ms 17 ms
40
11 ms 17 ms
45
12 ms 18 ms
50
12 ms 19 ms
53
12 ms 20 ms
55
12 ms 20 ms
60
13 ms 21 ms
68
13 ms 22 ms
75
14 ms 24 ms
80
14 ms 25 ms
83
14 ms 25 ms
90
15 ms 27 ms
100
16 ms 29 ms
105
16 ms 30 ms
120
17 ms 33 ms
135
18 ms 36 ms
140
19 ms 37 ms
150
19 ms 39 ms
160
20 ms 40 ms
165
20 ms 41 ms
180
22 ms 44 ms
200
23 ms 48 ms
220
24 ms 52 ms
240
26 ms 56 ms
Tab. 17: Number of beams
depending on the protective
field height and the physical
resolution
Tab. 18: Response time as
factor of the number of beams
