3.2.10 Status indicators
Overview
T
he sender and receiver LEDs indicate the operational status of the safety light curtain.
Sender displays
Figure 5: Sender indicators
T
he sender has one laser alignment aid and at least two light emitting diodes, which
indicate the operational status:
Position LED color Function Labeling
!
Red/yellow/green Field indicator
1)
;
sho
ws the status of
the protective field
and additional infor‐
mation about the sta‐
tus display
–
"
– Laser alignment aid –
§
Red/yellow/green Status indicator STATE
1)
Safety light curtains with protective field height > 300 mm have multiple LEDs for the field indicator.
3 PRODUCT DESCRIPTION
16
O P E R A T I N G I N S T R U C T I O N S | deTec4 8027140/2021-11-04 | SICK
Subject to change without notice
