13 Technical data
13.1 Data sheet
Table 27: General system data
Minimum Typical Maximum
Protective field height, depending on
t
ype
300 mm to 2,100 mm, 150 mm steps
Resolution (detection capability) 30 mm
Protective field width
1)
2)
3)
Resolution 30 mm 0 m … 24 m 0 … 30 m
Protection class
4)
III (IEC 61140)
Enclosure rating
5)
IP65 (IEC 60529)
IP67 (IE
C 60529)
Supply voltage U
V
a
t the device
6)
7)
19.2 V 24 V 28.8 V
Residual ripple
8)
± 10%
Synchronization Optical
Type Type 4 (IEC 61496-1)
Category Category 4 (ISO 13849-1)
Performance level
9)
PL e (ISO 13849–1)
Safety integrity level
9)
SIL 3 (IEC 61508)
SIL claim limit
9)
SILCL 3 (IEC 62061)
PFH
D
(me
an probability of a danger‐
ous failure per hour)
1.53 x 10
-8
T
M
(mis
sion time) 20 years (ISO 13849-1)
Safe status when a fault occurs At least one OSSD is in the OFF state.
Power-up delay of sender and
r
eceiver after supply voltage is
applied
2 s
Test rod speed at which the test rod
is reliably detected
10)
0 m/s … 1.6 m/s
1)
If the protective fields are very wide, there is a possibility that all four diagnostic LEDs 1, 2, 3 and 4 will
no
t light up even when alignment is optimal.
2)
The minimum scanning range specifies a range in which a function is guaranteed to operate correctly
and safely under industrial conditions. A sufficient level of signal reserve to ensure very high availability is
included in the calculation.
3)
The typical scanning range specifies a range in which the safety light curtain operates correctly and safely
under industrial conditions. The level of signal reserve is enough to ensure high availability.
4)
SELV/PELV safety extra-low voltage.
5)
The specified enclosure rating only applies when the system plug is fitted.
6)
The external voltage supply must be capable of bridging a brief power failure of 20 ms as specified in
IEC 60204-1. Suitable power supply units are available as accessories from SICK.
7)
A fuse rated maximum 2 A shall be installed in the 24 V DC power supply circuit to the device in order to
limit the available current.
8)
Within the limits of U
V
.
9)
For more detailed information on the exact configuration of your machine, please contact your relevant
SIC
K subsidiary.
10)
Direction of movement and axis of the test rod perpendicular to the protective field.
Table 28: Mechanical data
deTec4
Housing material Aluminum extruded profile
Front screen material PMMA
TECHNICAL DATA 13
