15.6.4 Deflector mirror PNS75 - ordering information
Table 56: Ordering information for PNS75 deflector mirror
Mirror length in mm Max. protective field
hei
ght in mm
Type code Part number
340 300 PNS75-034 1019414
490 450 PNS75-049 1019415
640 600 PNS75-064 1019416
790 750 PNS75-079 1019417
940 900 PNS75-094 1019418
1090 1050 PNS75-109 1019419
1240 1200 PNS75-124 1019420
1390 1350 PNS75-139 1019421
1540 1500 PNS75-154 1019422
1690 1650 PNS75-169 1019423
1840 1800 PNS75-184 1019424
1990 1950 PNS75-199 1092962
2140 2100 PNS75-214 1092963
15.6.5 Deflector mirror PNS125 - ordering information
Table 57: Ordering information, deflector mirror PNS125
Mirror length in mm Max. protective field
hei
ght in mm
Type code Part number
340 300 PNS125-034 1019425
490 450 PNS125-049 1019426
640 600 PNS125-064 1019427
790 750 PNS125-079 1019428
940 900 PNS125-094 1019429
1090 1050 PNS125-109 1019430
1240 1200 PNS125-124 1019431
1390 1350 PNS125-139 1019432
1540 1500 PNS125-154 1019433
1690 1650 PNS125-169 1019434
1840 1800 PNS125-184 1019435
1990 1950 PNS125-199 1092964
2140 2100 PNS125-214 1092965
15.7 Mirror columns
Table 58: Ordering information, mirror columns
Column height Mirror length Type code Part number
1,281.5 mm 1,082 mm PM3C13-00030000 1043453
1,569 mm 1,382 mm PM3C15-00030000 1077525
1,716.5 mm 1,532 mm PM3C17-00030000 1043454
2,016.5 mm 1,682 mm PM3C19-00030000 1043455
2,216.5 mm 1,832 mm PM3C20-00030000 1043456
2,269 mm 1,985 mm PM3C22-00030000 1093216
