Figure 47: Internal circuitry: pushbutton for laser alignment aid (5-pin)
S1
5
6
7
8
5
6
7
8
44
3
3
22
11
!
!
!
Figure 48: Internal circuitry: pushbutton for laser alignment aid (8-pin)
1
Unused. The connection is not required but may be present.
15.5 Alignment aid
Table 54: Alignment aid ordering information
Part Part number
AR60 laser alignment aid 1015741
Adapter 4070854
15.6 Deflector mirrors
15.6.1 Function and use
Overview
D
eflector mirrors can be used to shape the protective field to secure hazardous points
from multiple sides using a single safety light curtain.
15 A
