8 Commissioning
8.1 Safety
Important information
DANGER
H
azard due to lack of effectiveness of the protective device
When changes are made to the machine, the effectiveness of the protective device may
be affected unintentionally.
b
After every change to the machine and changes to the integration or operational
and secondary conditions of the safety light curtain, check the protective device
for effectiveness and recommission as specified in this section.
DANGER
Dangerous state of the machine
b
Make sure that the dangerous state of the machine is (and remains) switched off
during mounting, electrical installation, and commissioning.
b
Make sure that the outputs of the safety light curtain do not affect the machine
during mounting, electrical installation, and commissioning.
WARNING
H
azard due to lack of effectiveness of the protective device
b
Before commissioning the machine, make sure that the machine is first checked
and released by qualified safety personnel.
b
Only operate the machine with a perfectly functioning protective device.
Further topics
•
"Minimum dis
tance to reflective surfaces", page 26
8.2 Overview
Prerequisites
•
C
onfiguration has been completed correctly
•
Mounting has been completed correctly
•
Electrical installation has been completed correctly
Approach
1.
Check the DIP switches at the sender and receiver and set them correctly if
required.
2. Fitting the system plug.
3. Switch on the voltage supply.
°
If a change to the configuration is detected or the device has been reset to
factory settings, the device is in configuration mode and the field indicator
flashes green.
4. Configure the restart interlock if required.
5. Once configuration is complete, briefly interrupt the voltage supply, then switch it
back on.
6. If the configuration for the restart interlock or external device monitoring needs to
be changed, reset the device to factory settings.
