Diagnostic LEDs Color Configuration
4
O W
hite
Restart interlock is configured.
5
O W
hite
Reserved
6
O W
hite
Reserved
7
O W
hite
Reserved
8
O W
hite
Reserved
o LED of
f. Ö LED flashes. O LED illuminates.
Table 5: Indication of the alignment quality
Diagnostic LEDs Color Meaning
1 ... 4
O Blue
Indication of the alignment quality.
If onl
y one diagnostic LED lights up, the align‐
ment is insufficient. If all 4 diagnostic LEDs
light up, the alignment is excellent.
5, 6
O Blue
The topmost beam (far from system plug) is
s
ynchronized.
7, 8
O Blue
The bottommost beam (near system plug) is
synchronized.
o LED of
f. Ö LED flashes. O LED illuminates.
Table 6: Fault indicator
Diagnostic LEDs Color Meaning
1 ... 8
O Red
A red illuminated diagnostic LED signals the
f
unction at which an error has occurred.
1 ... 8
Ö R
ed
A red flashing diagnostic LED signals the rea‐
son f
or the error.
o LED of
f. Ö LED flashes. O LED illuminates.
Example: If diagnostic LED 1 lights up red and diagnostic LED 5 flashes red, there is an
EDM er
ror.
Table 7: Warnings
Diagnostics LED Color Meaning
1 ... 8
O Y
ellow
A yellow illuminated diagnostic LED signals
whic
h function is affected.
1 ... 8
Ö Y
ellow
A yellow flashing diagnostic LED signals the
r
eason for the warning.
o LED of
f. Ö LED flashes. O LED illuminates.
Further topics
•
"Dia
gnostic LEDs", page 70
3 P
RODUCT DESCRIPTION
18
O P E R A T I N G I N S T R U C T I O N S | deTec4 8027140/2021-11-04 | SICK
Subject to change without notice
