3 Product description
3.1 Product ID
3.1.1 Type label
The type label is attached on the housing side with the electrical connections.
D-79276 Reute
Made in Germany
1
2
4
6
3
7
8
ß
9
à
5
CLV631-0831S01
P/N: 1062070
S/N: 1249 0001
DC 18...30V 8.5W
Imax=800mA
Pmax=7.0mW
P<1.0mW average
λ=655nm
Pulse duration <80μS
MAC 00:00:00:00:00:00
Manufactured: April 2017
Figure 4: Type label on IP69K protective housing (example)
1
Type designation
2
Part number
3
Serial number
4
Supply voltage and power consumption
5
Maximum current consumption
6
Maximum laser output
7
Average laser output
8
Laser wavelength
9
Laser pulse duration
ß
MAC address
à
Date of manufacture
3 PRODUCT DESCRIPTION
