CLV630 CLV631 CLV632
Device weight
2
Front reading window: 890 g, incl. double protective bushing
Side reading window: 1,230 g, incl. double protective bushing
Safety EN 60950-1
Electrical protection class III (EN 61140)
Enclosure rating IP69K (DIN 40050, Part 9)
Test conditions:
•
Water spray quantity: 14 ... 16 l/min
•
Water pressure/temperature: 10,000 KPa (100 bar) / 80 °C
•
Fan nozzle distance: 100 mm ... 150 mm
•
Spray angle: 0°, 30° , 60°, 90°
•
Cycle: 30 s for each position
•
Rotational speed of test specimen: 5 rpm
1
See also see figure 6, page 12 and see figure 7, page 13
2
Without connecting cables
Ambient data
CLV630 CLV631 CLV632
EMC test Radiated emission: in accordance with EN 61000-6-3 (2007-01)
Immunity: in accordance with EN 61000-6-2 (2005-08)
Vibration resistance EN 60068-2-6: 2008-02
Shock resistance EN 60068-2-27: 2009-05
Ambient operating tempera‐
ture
0 °C ... +40 °C
Storage temperature –20 °C ... +70 °C
Permissible relative humidity 0% ... 90%, non-condensing
Ambient light immunity 2,000 lx, on bar code
Bar code print contrast (PCS) ≥ 60%
7.3 Bar code scanner CLV64x in IP69K protective housing
NOTE
The relevant online data sheet for your product including technical data and dimen‐
sions can be downloaded from the Internet: www.sick.com/CLV64x
Optics
CLV640
Working range Standard density
Scanning method Line scanner, grid scanner
1)
, or line scanner with oscillating mirror, for identifier see type
code in operating instructions
Reading window orientation Front or side, for identifier see type code in operating instructions
Aperture angle ≤ 50°
Scan/decoder frequency 400 Hz … 1,200 Hz
Resolution 0.15 mm ... 1.0 mm (type-dependent)
Focus Dynamic focus adjustment
Light source Laser diode, visible red light (λ = 655)
MTTF (laser diode) 40,000 h at 25 °C
TECHNICAL DATA 7
8021479/0000/2018-03-12 | SICK T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing
31
Subject to change without notice
