SICK CLV63 Series Technical Information

8 Accessories
8.1 Brackets
SICK offers prefabricated brackets which are optimally suited for mounting the device
in a wide range of applications. Also see on Internet at:
■
www.sick.com/CLV62x
■
www.sick.com/CLV63x
■
www.sick.com/CLV64x
Figure 22: Example of optional bracket for bar code scanners CLV62x, CLV63x and CLV64x with
front reading window in IP69K protective housing, here round pole bracket with mounting
bracket, part number 2068599
Figure 23: Example of optional bracket for bar code scanners CLV62x, CLV63x and CLV64x with
oscillating mirror and side reading window, in IP69K protective housing, here mounting plate,
part number 2068602
8.2 Cables
NOTICE
The following requirements must be met in order to achieve the IP69K enclosure rating:
•
Use only the connection cables specified by SICK.
•
Seal the two cable outlets at the protective double bushing with the corresponding
O-rings.
The O-rings are included in the device scope of delivery and are matched to the outer
diameters of the plug connectors.
The following connection cables are available as accessories for the devices.
8 ACCESSORIES
34
T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing 8021479/0000/2018-03-12 | SICK
Subject to change without notice
