CLV640
Configuration SOPAS ET configuration software, profile programming with bar codes, command language,
GSD configuration
Mechanics/electronics
CLV640
Electrical connection Ethernet version: 2 x round connections (1 x male connector, M12, 17-pin, A-coded, 1 x
female connector, M12, 4-pin, D-coded)
Supply voltage 18 V DC ... 30 V DC, LPS or NEC Class 2, reverse polarity protected
Power consumption Typically 5 W, with no loading of switching outputs
Housing Stainless steel
Housing color Unpainted
Reading window material Plastic
Device dimensions (L x W x
H)
1)
Front reading window: 85 mm x 84 mm x 154 mm
Side reading window (oscillating mirror): 121 mm x 84 mm x 164 mm
Device weight
2)
Front reading window: 890 g, incl. double protective bushing
Side reading window: 1,230 g, incl. double protective bushing
Safety EN 60950-1
Electrical protection class III (EN 61140)
Enclosure rating IP69K (DIN 40050, Part 9)
Test conditions:
•
Water spray quantity: 14 ... 16 l/min
•
Water pressure/temperature: 10,000 KPa (100 bar) / 80 °C
•
Fan nozzle distance: 100 mm ... 150 mm
•
Spray angle: 0°, 30° , 60°, 90°
•
Cycle: 30 s for each position
•
Rotational speed of test specimen: 5 rpm
1)
See also see figure 6, page 12 and see figure 7, page 13
2)
Without connecting cables
Ambient data
CLV640
EMC test Radiated emission: in accordance with EN 61000-6-3 (2007-01)
Immunity: in accordance with EN 61000-6-2 (2005-08)
Vibration resistance EN 60068-2-6: 2008-02
Shock resistance EN 60068-2-27: 2009-05
Ambient operating tempera‐
ture
0 °C ... +40 °C
Storage temperature –20 °C ... +70 °C
Permissible relative humidity 0% ... 90%, non-condensing
Ambient light immunity 2,000 lx, on bar code
Bar code print contrast (PCS) ≥ 60%
TECHNICAL DATA 7
8021479/0000/2018-03-12 | SICK T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing
33
Subject to change without notice
