Item Component Description
1 Protective double bushing for the two
electrical connections in the terminal
compartment
Seals the connections and the two cable
outlets to the outside. Use of both bush‐
ings or only one bushing with dummy plug
for the free bushing.
Protective double bushing equipped with:
•
Recessed flat seal on the side to the
protective housing
•
One internal groove in each case at
the end of the bushings (cable out‐
let) to accommodate an O-ring for
sealing
•
Two captive mounting screws for
securing on the protective housing
2 O-ring
Inside diameter x cord thickness:
11.0 mm x 4.0 mm
Seals the plug connector for the “Ether‐
net” connection towards the protective
double bushing.
One O-ring serves as a spare part.
2 O-ring
Inside diameter x cord thickness:
13.5 mm x 3.0 mm
Seals the plug connector for the “Power/
Serial Data/CAN/I/O” connection towards
the protective double bushing.
One O-ring serves as a spare part.
1 Dummy plug Seals the free bushing of the protective
double bushing if the Ethernet connection
is not used. Matching O-ring: 11.0 mm x
4.0 mm.
3.4 Differences between devices in IP65 standard housing and devices in IP69K pro‐
tective housing
Table 3: Differences between devices in IP65 standard housing and devices in IP69K protective
housing
Feature Devices in IP65 standard housing Devices in IP69K protective housing
Housing variant Front reading window: CLV62x,
CLV63x and CLV64x
Front reading window: CLV62x,
CLV63x and CLV64x
Side reading window and oscillating
mirror: CLV63x and CLV64x
Side reading window and oscillating
mirror: CLV63x and CLV64x
Side reading window: CLV62x,
CLV63x and CLV64x
––
Housing material Die-cast aluminum Stainless steel
Housing color Blue, painted Unpainted
Enclosure rating IP65 IP69K
Reading window Glass or plastic Plastic
Reading fields For glass: 100%
For plastic: depth of field reduced by
10%
Depth of field reduced by 10%
Distance to device smaller
Laser warning
label
Stuck on Lasered on
Status displays CLV62x: 6 LEDs
CLV63x and CLV64x: 6 LEDs and bar
graph display
Omitted
Operating but‐
tons
CLV62x: None
CLV63x and CLV64x: 2
Omitted
3 PRODUCT DESCRIPTION
14
T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing 8021479/0000/2018-03-12 | SICK
Subject to change without notice
