7 Technical data
7.1 Bar code scanner CLV62x in IP69K protective housing
NOTE
The relevant online data sheet for your product including technical data and dimen‐
sions can be downloaded from the Internet: www.sick.com/CLV62x
Optics
CLV620
Working range Mid range
Scanning method Line or grid scanner
1)
, for identifier see type code in operating instructions
Reading window orientation Front, for identifier see type code in operating instructions
Aperture angle ≤ 50°
Scan/decoder frequency 400 Hz … 1,200 Hz
Resolution 0.2 mm ... 1.0 mm
Focus Fixed focus
Light source Laser diode, visible red light (λ = 655 nm)
MTBF (laser diode) 40,000 h at 25 °C
Laser class Class 2 in accordance with EN/IEC 60825-1:2014 (identical laser class to EN/IEC
60825-1:2007). Complies with 21 CFR 1040.10 except for tolerances according to Laser
Notice no. 50 of June 24, 2007 and its following versions.
Laser power (maximum/aver‐
age)
1.5 mW / < 1.0 mW
Laser pulse duration < 300 μs
1)
Grid height approx. 15 mm at a reading distance of 200 mm
Performance
CLV620
Bar code types Code 39, Code 128, Code 93, Codabar, GS1-128 / EAN 128, UPC / GTIN / EAN, 2/5 Inter‐
leaved, Pharmacode, GS1 DataBar, Telepen, MSI/Plessey
Print ratio 2:1 ... 3:1
No. of codes per scan 1 ... 20 (standard decoder)
1 ... 6 (SMART620)
No. of codes per reading
interval
1)
1 ... 50 (auto-discriminating)
No. of characters per code/
reading interval
Max. 50 characters / max. 5,000 characters across all bar codes per reading interval, 500
characters for multiplexer function (CAN)
Number of multiple readings 1 ... 99
1)
Reading interval: The time window generated internally by the reading cycle for code detection and evaluation
Interfaces
CLV620
Serial (RS-232,
RS-422/-485)
Function: Host, AUX
Data transmission rate: 2.4 kBd ... 115.2 kBd, AUX: 57.6 kBd (RS-232)
Ethernet Function: Host, AUX
Data transmission rate: 10/100 Mbit/s, half/full duplex
Protocol: TCP/IP, EtherNet/IP, PROFINET Single Port
TECHNICAL DATA 7
8021479/0000/2018-03-12 | SICK T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing
27
Subject to change without notice
