SICK CLV63 Series Technical Information

Feature Devices in IP65 standard housing Devices in IP69K protective housing
Optional plug-in
memory card for
parameter
cloning
CLV62x: None
CLV63x and CLV64x: 1
Omitted
Mounting 2 x 2 blind tapped hole M5, 5 mm
deep
4 x holes 5.5 mm
2 x threaded holes M5
SOPAS ET Shows the reading field of the
devices in the standard housing
Shows the reading field of the
devices in the standard housing
3.5 Reading fields
The reading fields of the devices in IP69K protective housing differ from the devices in
IP65 standard housing with respect to the position of the housing edge and the depth
of field.
■
Position: The distance between the reading field and housing edge is smaller than
on the standard devices in the case of devices in IP69K protective housing. The
reason for this is the longer light path in the IP69K protective housing.
■
Depth of field: On devices in the IP69K protective housing, the depth of field is
reduced by approx. 10% (reduction of reading fields on both sides by 5% in each
case for all module widths). This is due to the reading window made of plastic.
On devices in IP69K protective housing, the distance between the reading window and
housing edge is reduced as follows compared with the reading window (glass) of a
device in the standard housing:
■
Bar code scanner with front reading window: 10.7 mm
■
Bar code scanner with oscillating mirror and side reading window: 11.16 mm
Example: reading fields of the CLV631 with front reading window
The following table shows the reading fields of two comparable bar code scanners with
front reading window by way of example.
PRODUCT DESCRIPTION 3
8021479/0000/2018-03-12 | SICK T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing
15
Subject to change without notice
