SICK CLV63 Series Technical Information

Table 4: CLV631 reading fields with front reading window
CLV631 in standard housing CLV631 in IP69K protective housing
500
(19.69)
300
(11.81)
400
(15.75)
200
(7.87)
100
(3.94)
0
Reading distance in mm (inch) 2
Resolution 3
a: 0.25 mm (9.8 mil)
c: 0.50 mm (19.7 mil)
b: 0.35 mm (13.8 mil)
–100
(–3.94)
–200
(–7.87)
100
(3.94)
200
(7.87)
0
Reading field height in mm (inch) 1
a
b
c
Figure 8: Reading field diagram of CLV631-0120, reading win‐
dow at front
1
Reading field height in mm (inch)
2
Reading distance in mm (inch)
3
Resolution
0
0
a
b
c
–100
(–3.94)
–200
(–7.87)
100
(3.94)
200
(7.87)
Reading field height in mm (inch) 1
Reading distance in mm (inch) 2
500
(19.69)
300
(11.81)
400
(15.75)
200
(7.87)
100
(3.94)
Resolution 3
a: 0.25 mm (9.8 mil)
c: 0.50 mm (19.7 mil)
b: 0.35 mm (13.8 mil)
Figure 9: Reading field diagram of CLV631-0831S01, front
reading window
1
Reading field height in mm (inch)
2
Reading distance in mm (inch)
3
Resolution
Example: reading fields of CLV631 with oscillating mirror and side reading window
The following table shows the reading fields of two comparable bar code scanners with
oscillating mirror and side reading window by way of example.
3 PRODUCT DESCRIPTION
16
T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing 8021479/0000/2018-03-12 | SICK
Subject to change without notice
