Connection cables for “Power/Serial data/CAN/I/O” connection
Table 8: Connection cables for “Power/Serial data/CAN/I/O” connection
Part number Description
6051194 Connection cable with female and male connector, 17-wire, shielded
Head A: female connector, M12, 17-pin, straight, A-coded
Head B: male connector, M12, 17-pin, straight, A-coded
Length: 3 m
6051195 As 6051194, but length 5 m
2070425 Connection cable with female connector and cable, 17-wire, shielded
Head A: female connector, M12, 17-pin, straight, A-coded
Head B: open cable end, wires stripped
Length: 3 m
2070426 As 2070425, but length 5 m
2070427 As 2070425, but length 10 m
NOTE
For cables with an open end at one end, the signal-neutral assignment of contacts of
the female or male connector to the wire colors can be viewed on the Internet at:
www.sick.com
b
For this purpose, enter the 7-digit part number of the cable in the search field.
For the device-specific signal assignment of the contacts, see this document, see "Pin
assignment of the connections", page 25.
Connection cables for “Ethernet” connection
Table 9: Connection cables for “Ethernet” connection
Part number Description
6050198 Connection cable with male and male connector, 4-wire, AWG26, shielded
Head A: male connector, M12, 4-pin, straight
Head B: male connector, RJ45, 8-pin, straight
Length: 2 m
6050199 As 6050198, but length 3 m
6050200 As 6050198, but length 5 m
6050201 As 6050198, but length 10 m
6050596 As 6050198, but length 20 m
ACCESSORIES 8
8021479/0000/2018-03-12 | SICK T E C H N I C A L I N F O R M A T I O N | CLV62x, CLV63x and CLV64x with IP69K Protective Housing
35
Subject to change without notice
