SICK CLV63x - CLV65 x Reading Field Diagrams

12.6.3.2 High resolution
Reading distance in mm (inch)
300
(11.81)
250
(9.84)
200
(7.87)
150
(5.91)
100
(3.94)
50
(1.97)
0
250
(9.84)
200
(7.87)
150
(5.91)
100
(3.94)
50
(1.97)
0
Focus position in mm (inch)
Resolution 0.15 mm (5.9 mil)
max. reading distance (aperture angle 25°)
min. reading distance
A
B
A
B
Figure 53: Reading field diagram CLV642, resolution 0.15 mm, reading window on front
12.6.4 Overview of CLV65x reading field diagrams
12.6.4.1 Standard resolution
0
600 1,000 1,400 1,800
200
a
b
c
d
Reading field height in mm
Reading distance in mm
400
200
–200
–400
0
Resolution
a: 0.25 mm
c: 0.50 mm
d: 1.00 mm
b: 0.35 mm
Figure 54: Reading field diagram CLV650, reading window on front
TECHNICAL DATA 12
8019588/2017-01-20 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
71
Subject to change without notice
