SICK CLV63x - Page 72

0
600 1,000 1,400 1,800
200
a
b
c
d
Reading field height in mm
Reading distance in mm
400
200
–200
–400
0
Resolution
a: 0.25 mm
c: 0.50 mm
d: 1.00 mm
b: 0.35 mm
Figure 55: Reading field diagram CLV650, oscillating mirror, reading window on side
400
(15.75)
500
(19.69)
100
(3.94)
200
(7.87)
300
(11.81)
–400
(–15.75)
–500
(–19.69)
–100
(–3.94)
–200
(–7.87)
–300
(–11.81)
0
400
(15.75)
600
(23.62)
800
(31.50)
1,000
(39.37)
1,200
(47.24)
1,400
(55.12)
200
(7.87)
0
Reading distance in mm (inch)
For devices w
ith plastic reading window, the depth of
field is reduced by approx. 10 %.
Resolution
a: 0.25 mm (9.8 mil)
c: 0.50 mm (19.7 mil)
d: 1.00 mm (39.4 mil)
b: 0.35 mm (13.8 mil)
Reading field height in mm (inch)
a
b
c
d
Figure 56: Reading field diagram CLV650-0120S01, reading window on front
12
TECHNICAL DATA
72
O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/2017-01-20 | SICK
Subject to change without notice
