500 700 900 1100 1300 1500 1700 1900 2100
1300
1200
1100
1000
900
800
700
600
Scanning frequency (Hz)
Radial reading distance (mm)
Resolution:
0.35mm
0.50mm
Standard Density: line scanner with oscillating mirror CLV690-1xxx
Figure 93: CLV690-1xxx (Standard Density): scanning frequency characteristic curve depending on the radial reading distance
and resolution
-400 0 400 800 1200 1600 2000 2400
-400
0
400
800
1200
1600
0.50mm
0.30mm
0.35mm
Resolution:
0.30mm
0.35mm
0.50mm
Deflection width (mm)
Radial reading distance (mm)
Standard Density: line scanner with oscillating mirror CLV690-1xxx
Angle of deflection max. 40°
Figure 94: CLV690-1xxx (Standard Density): deflection width depending on the radial reading distance, angle of deflection and
resolution
12
TECHNICAL DATA
110
O P E R A T I N G I N S T R U C T I O N S | CLV69x 8014396/ZMG8/2017-07-04 | SICK
Subject to change without notice
