SICK CLV69x User Manual

500 700 900 1100 1300 1500 1700 1900 2100
1300
1200
1100
1000
900
800
700
600
Low Density: line scanner CLV691-0xxxScanning frequency (Hz)
Radial reading distance (mm)
Resolution:
0.50mm
Figure 98: CLV691-0xxx (Low Density): scanning frequency characteristic curve depending on the radial reading distance and
resolution
12.6.6 Low Density: reading performance data, line scanner with oscillating mirror
400
800
600
400
200
–200
–400
–600
–800
0
700 1000 1300 1600 1900 2200
Reading field height in mm
Resolution 0.5mm
Tilt ± 45°
Tilt ± 30°
Tilt ± 15°(typical values)
Reading distance in mm
Figure 99: CLV691-1xxx (Low Density): reading field height depending on the reading distance and tilt with resolution 0.5 mm
12
TECHNICAL DATA
114
O P E R A T I N G I N S T R U C T I O N S | CLV69x 8014396/ZMG8/2017-07-04 | SICK
Subject to change without notice
