SICK CLV69x User Manual

500 700 900 1100 1300 1500 1700 1900 2100
1300
1200
1100
1000
900
800
700
600
Low Density: line scanner with oscillating mirror CLV691-1xxxScanning frequency (Hz)
Radial reading distance (mm)
Resolution:
0.50mm
Figure 100: CLV691-1xxx (Low Density): scanning frequency characteristic curve depending on the radial reading distance and
resolution
-400
0
400
800
1200
1600
Radial reading distance (mm)
-400 0 400 800 1200 1600 2000 2400
Low Density: line scanner with oscillating mirror CLV691-1xxx
Angle of deflection max. 40°
Deflection width (mm)
‒15° ... +15°
‒45° ... +45°
‒30° ... +30°
Resolution 0.5mm:
Tilt:
‒45° ... +45°
‒30° ... +30°
‒15° ... +15° (typical values)
Figure 101: CLV691-1xxx (Low Density): deflection width depending on the radial reading distance, angle of deflection and tilt
with resolution 0.5 mm
TECHNICAL DATA
12
8014396/ZMG8/2017-07-04 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV69x
115
Subject to change without notice
